electromagnetic water flow meter sensor price
Electromagnetic Flow Meter , also referred to as mag flow meter or magmeter, is a volumetric flow meter that measures liquids or liquid slurries that have a minimum conductivity of 5 µS/cm.
Magnetic flow meters will typically not work with hydrocarbons, distilled water, non-aqueous solutions and non-conductive solutions.Electromagnetic Water Flow Meter Sensor Price

Typical Industries Where Magnetic Flow Meters are Used

  • Water / Wastewater Industry
  • Food and Beverage
  • Metals
  • Brewing, Distilling, and Wine makening
  • HVAC
  • Chemical
  • Pulp and Paper
  • Pharmaceutical
  • Mining, Mineral Processing

Application area

1. Drinking water supply, water supply, reservoir and pumping station etc.

2. Chemical acid, lye, conductive solution, cooling fluid, additives etc.

3. Drink water, beer, wine, alcohol, milk, yogurt, fruit juice, syrup, blood etc.

4. Refrigeration / air conditioning and refrigeration thermal measurement, or heat energy.

5. Sewage, industrial sewage discharge, sewage etc.

6.Control of metal industrial pump,cooling water and the flow of water.

7. The textile industry of water, pigments, chemicals, bleaching chemicals etc.

Electromagnetic Water Flow Meter Sensor Price
Magnetic flow meters require a minimum medium conductivity for the technology to measure flow. This
chart provides a general guideline on conductivity of common media


Electromagnetic Water Flow Meter Sensor Price
Flow rate:

Electromagnetic flow meter flow rate range
SizeMin flow m3/hNormal flow rate m3/hMax flow m3/h
DN150.060.193.186.36
DN200.110.335.6511.31
DN250.170.538.8317.67
DN320.280.8614.4728.94
DN400.451.3522.6145.23
DN500.712.1235.3570.68
DN651.193.5859.72119.45
DN801.815.4290.47180.95
DN1002.828.48141.37282.74
DN1254.4113.25220.85441.71
DN1506.3619.08318.08636.17
DN20011.3133.92565.481130.97
DN25017.6753.01883.571767.14
DN30025.4476.341272.342544.69
DN35034.63103.911731.83463.6
DN40045.23135.712261.944523.89
DN45057.25171.762862.775725.55
DN50070.68212.053534.297068.58
DN600101.78305.365089.3810178.76
DN700138.54415.636927.2113854.42
DN800180.95542.869047.7818095.57

Electromagnetic Water Flow Meter Sensor Price

Order sheet

Name

Specification code

Explanation

Instrument type



electromagnetic water flow meter sensor price

Diameter code

AT-xxx

For example:100 represents DN100

Electrode form

1

Standard stationary type









Electrode material

0

Stainless steel(316L)

1

Platinum Pt

2

Hastelloy B(HB)

3

Tantalum Ta

4

Titanium Ti

5

Hastelloy C(HC)







Lining material

3

Chloroprene rubber

4

Polyurethane rubber

5

F4(PTFE) polytetrafluoroethylene

6

F46(FEP)polyperfluoroethylene-propylene







Rated pressure(MPa)

1.6

DN10-80

1.6

DN100-150

1.0

DN200-1000

0.6

DN1100-2000

0.25

DN2200



Operating temperature

E

<80ºC

H

<120ºC

Grounding



Built-in grounding electrode

Grade of  protection

0

IP65

1

IP68

Converter type

0

Integral type

1

Split type

Case material

0

Carbon steel

1

Stainless steel

Instrument flange

0

Carbon steel

1

Stainless steel

Installing timing flange

0

Without

1

With

Power supply source

0

220VAC

1

24VDC


Installation :

Electromagnetic Water Flow Meter Sensor Price

Electromagnetic Water Flow Meter Sensor Price
Electromagnetic Water Flow Meter Sensor Price
calibration line:


Electromagnetic Water Flow Meter Sensor Price

real  picture:

Electromagnetic Water Flow Meter Sensor Price
Electromagnetic Water Flow Meter Sensor Price
Electromagnetic Water Flow Meter Sensor Price
Electromagnetic Water Flow Meter Sensor Price
electromagnetic water flow meter sensor price
